We uphold the spirit of 'integrity, responsibility, detail, and innovation', follow the latest development trend of seamless stator tube, 1020 Pre Honed Tube, 1045 Cold Drawn Honed Tube, and continuously improve the company's service level and product quality with outstanding talents, advanced technology and scientific management. We take 'excellent quality, accurate delivery, and considerate service' as our promise, and look forward to sincere cooperation with you! While focusing on economic benefits, we also pay more attention to the social benefits of enterprises, and gain economic and social benefits through the principle of honest management. We uphold the passion and excellence corporate philosophy, insist on taking the road of modern enterprise development through years of unremitting efforts.
Honed Tube For Hydraulic Cylinder Introduction
Honed Tubes are presicion tubes with smooth inside, they also could be skived and burnished pipe. Tubes or pipes inside tolerance could be H10, H9 or H8. Outside tolerance, wall thickness tolerance are produced according to seamless cold drawn tubes for precision application standard GB/T3639-2009 , EN10305 or DIN2391 standard. Material SAE1020, 20#, ST45, CK45, ST52, E355 tubes and so on for you to choose.
Honed Tubes technical parameters and Details
Application: hydraulic cylinder, pneumatic cylinder, oil cylinder, telescopic cylinder.
Original: Jiangsu, China
Certification: ISO9001.
Material: SAE1020, 20#, ST45, CK45, ST52, E355
Payment term: TT, LC
Delivery date: usually 20 to 40 days.
Packing: packed in bundle, oiled inside, with caps on both ends.
Market: Middle East/ Africa/Asia/South America/Europe/North America
MOQ: Depends on exact size and material.
Chemical Properties:
Material | C% | Mn% | Si% | S% | P% |
20# | 0.17-0.23 | 0.35-0.65 | 0.17-0.37 | ≤0.035 | ≤0.035 |
ST45 | ≤0.21 | ≥0.4 | ≤0.35 | ≤0.025 | ≤0.025 |
E255 | ≤0.21 | 0.4-1.1 | ≤0.35 | ≤0.025 | ≤0.025 |
45# | 0.42-0.50 | 0.50-0.80 | 0.17-0.37 | ≤0.035 | ≤0.035 |
Q345B | ≤0.20 | ≤1.70 | ≤0.50 | ≤0.035 | ≤0.035 |
E355 | ≤0.22 | ≤1.6 | ≤0.55 | ≤0.025 | ≤0.025 |
ST52 | ≤0.22 | ≤1.6 | ≤0.55 | ≤0.04 | ≤0.04 |
25Mn | 0.22-0.29 | 0.70-1.0 | 0.17-0.37 | ≤0.035 | ≤0.035 |
27SiMn | 0.24-0.32 | 1.10-1.40 | 1.10-1.40 | ≤0.035 | ≤0.035 |
Size list: (if you need other sizes, please let us know)
Honed Tubes characteristics
1. The inside tolerance could up to H8.
2. Honing Inside roughness could reach to Ra 0.4um. Skiving inside could reach to Ra 0.2 um.
3. ID size from 50 to 280mm, OD size from 60 to 370mm, totally has more than 200 sizes.
4. Length could be fixed length of random length.
5. Inside chrome plated is for optional.
Experience and markets
Our factory has more than 20years working experiences on researching and selling. Products are well sailed all over the world, got many compliments from customers.
We carry on to produce and structure top-quality excellent solutions for DIN2391 St52 H8 Tolerance Honed Tube for Hydraulic Cylinder. Over the years, we have been adhering to the business policy of 'customer first, pursuit of excellence, eternal innovation, and mutual benefit', and have won praises from many customers with the joint efforts of all the staff. Over the years, our company adheres to the market demand-oriented, consumer needs as the core business philosophy and constantly develop new products.
