16Mn Hydraulic Steel Tube Introduction
Honed Tubes are presicion tubes with smooth inside, they also could be skived and burnished pipe. Tubes or pipes inside tolerance could be H10, H9 or H8. Outside tolerance, wall thickness tolerance are produced according to seamless cold drawn tubes for precision application standard GB/T3639-2009 , EN10305 or DIN2391 standard. Material SAE1020, 20#, ST45, CK45, ST52, E355 tubes and so on for you to choose.WUXI HENGTONG PETROLIC MACHINERY has two factories of 40000 square meters and totally 150 employees manufactures 1020 Hydraulic Honed Tube.
16Mn Hydraulic Steel Tubes Specifications
Cylinder ID: 40mm-400mm Thickness:≥4mm
Material:20#(A106B,C20),45#(CK45),16Mn(ST52,E355),25Mn,27SiMn
Standard:GB/T8713-88 ISO4394/1-1980(EN0305,DIN2391)
Product | seamless steel tube | |
Standard | EN10305/DIN2391 | |
ISO4394/1-1980 | ||
GB/T8713-88 | ||
Material | China | 20# 45#(CK45) 16Mn(ST52) 25Mn 27SiMn etc. |
German | St42-2 DIN1626,St45-8 DIN17175,St45-4 DIN1629,CK45,St52 DIN1629 | |
American | ASTM A53-B,ASTM A106-B,ASTM A178-C,ASTM A1045,ASTM A210-C etc. | |
Length | as your requirements | |
Surface treatment | Black painting, black varnish, transparent oil, hot galvanized, 3PE, epoxy coating,BE,PE.etc. | |
Technique | Seamless & welded | |
Usage | 1.hydraulic cylinder /pneumatic cylinder | |
Package | 1. Bundle packing. | |
MOQ | as your needs | |
Mechanical propererty
| | | | |||
| T.S
| | | | | |
20# (C20.A106B) | ≥550 | ≥8 | ≥520 | ≥470 | ≥12 | 175 |
45#(CK45) | ≥650 | ≥5 | ≥600 | ≥520 | ≥12 | 207 |
16Mn | ≥640 | ≥5 | ≥600 | ≥520 | ≥15 | 190 |
25Mn (ST52.E355) | ≥640 | ≥5 | ≥600 | ≥510 | ≥15 | 195 |
27SiMn | ≥840 | ≥5 | ≥800 | ≥720 | ≥10 | 230 |
Tolerance on ID (GB1808-99)
| (Tolerance on OD)um | |||
H7 | H8 | H9 | H10 | |
30 | +210 | +330 | +520 | +840 |
>30-50 | +250 | +390 | +620 | +1000 |
>50-80 | +300 | +460 | +740 | +1200 |
>80-120 | +350 | +540 | +870 | +1400 |
>120-180 | +400 | +630 | +1000 | +1600 |
>180-250 | +460 | +720 | +1150 | +1850 |
>250-315 | +520 | +810 | +1400 | +2100 |
>315-400 | +570 | +890 | +1700 | +2300 |
