Highly-quality making certain subsistence, Administration marketing benefit, Credit score attracting customers for Round Chrome Bar, Hydraulic Honed Tube, Carbon Steel Seamless Honed Tube. We will continue to uphold the business philosophy of creating contributions that we have adhered to so far. Our company will, as always, be demand-oriented, research and development as the driving force, and quality as the core. We always strive to achieve the perfect balance between quality and cost performance. When It produced, it making use of the world's major method for reliable operation, a low failure price, it appropriate for Jeddah shoppers choice.
1020 Hydraulic Honed Tube Introduction
Honed Tubes are presicion tubes with smooth inside, they also could be skived and burnished pipe. Tubes or pipes inside tolerance could be H10, H9 or H8. Outside tolerance, wall thickness tolerance are produced according to seamless cold drawn tubes for precision application standard GB/T3639-2009 , EN10305 or DIN2391 standard. Material SAE1020, 20#, ST45, CK45, ST52, E355 tubes and so on for you to choose.WUXI HENGTONG PETROLIC MACHINERY has two factories of 40000 square meters and totally 150 employees manufactures 1020 Hydraulic Honed Tube.
Hydraulic Honed Tubes technical parameters and Details
Application: hydraulic cylinder, pneumatic cylinder, oil cylinder, telescopic cylinder.
Original: Jiangsu, China
Certification: ISO9001.
Material: SAE1020, 20#, ST45, CK45, ST52, E355
Payment term: TT, LC
Delivery date: usually 20 to 40 days.
Packing: packed in bundle, oiled inside, with caps on both ends.
Market: Middle East/ Africa/Asia/South America/Europe/North America
MOQ: Depends on exact size and material.
Size and Tolerance:
Working method | Cylinder ID （mm） | Length （m） | Straightness （mm/m） | Tolerance on ID | Tolerance on WT | Roughness （μm） |
Cold drawn | 40-320 | ≤12M | 0.2-0.5 | / | ±5% | 0.8-1.6 |
Cold rolling | 30-100 | ≥12M | 0.2-0.5 | / | ±5% | 0.8-1.2 |
cold drawn- honed | 40-500 | 8M | 0.2-0.3 | H8-H9 | ±5% | 0.2-0.8 |
Cold drawn-skived | 40-400 | 7M | 0.2-0.3 | H8-H9 | ±5% | ≤0.4 |
Deep hole boring- honed | 320-400 | 8M | 0.2-0.3 | H7-H9 | ±8% | ≤0.8 |
Deep hole boring- skived | 320-400 | 7M | 0.2-0.3 | H8-H9 | ±8% | ≤0.4 |
Honed Tubes characteristics
1. The inside tolerance could up to H8.
2. Honing Inside roughness could reach to Ra 0.4um. Skiving inside could reach to Ra 0.2 um.
3. ID size from 50 to 280mm, OD size from 60 to 370mm, totally has more than 200 sizes.
4. Length could be fixed length of random length.
5. Inside chrome plated is for optional.
Experience and markets
Our factory has more than 20years working experiences on researching and selling. Products are well sailed all over the world, got many compliments from customers.
We generally believe that one's character decides products' top quality, the details decides products' high-quality, along with the REALISTIC, EFFICIENT AND INNOVATIVE team spirit for Honed Cylinder Barrel 904 Seamless Tube. We provide high-quality products and reasonable prices with a sincere and honest attitude hoping to cooperate with you for a long time. We always follow that quality is foundation while service is guarantee to meet all customers.
