Big Cylinder Honed Tubes Honing Pipe introduction
Honed Tubes are presicion tubes with smooth inside , they also could be skived and burnished pipe. Tubes or pipes inside tolerance could be H10, H9 or H8. Outside tolerance, wall thickness tolerance are produced according to seamless cold drawn tubes for precision application standard GB/T3639-2009 , EN10305 or DIN2391 standard.WUXI HENGTONG PETROLIC MACHINERY manufactures Hydraulic Cylinder Honed Pipe, ready to hone tubes, honed tubes, skived and roller burnished tubes, chrome bar, piston rods and high-precision cold-drawn steel tubes.
Big Cylinder Honed Tubes Honing Pipes detail
Application: producing of hydraulic/ pneumatic cylinders, pumps, motor shells, transmission shafts and transmission roller steel pipes.
Original: Jiangsu, China
Certification: ISO9001.
Material: SAE1020, 20#, ST45, CK45, ST52, E355
Payment term: TT, LC
Delivery date: usually 20 to 40 days.
Packing: packed in bundle, oiled inside, with caps on both ends.
Market: Middle East/ Africa/Asia/South America/Europe/North America
MOQ: Depends on exact size and material.
Large diameter honing tube pneumatic cylinder tube For pipes / tubes:
1. Material we have :
DIN2391 standard ST52, St45, EN10305 standard E355,E255, ASTM A106B grade, 16Mn, C20/20#, CK45
2. Chemical composition:
Material | C | Si | Mn | S(≤) | P(≤) | Cr | Ni | Mo | other |
A106B/ C20# | 0.17—0.23 | 0.17—0.37 | 0.35—0.65 | 0.035 | 0.035 | ≤0.25 | ≤0.30 | Cu≤0.25 | |
CK45# | 0.42—0.50 | 0.17—0.37 | 0.50—0.80 | 0.035 | 0.035 | ≤0.25 | ≤0.30 | Cu≤0.25 | |
Q345B | ≤0.20 | ≤0.55 | 1.00—1.60 | 0.040 | 0.040 | V:0.02-0.15 | Nb:0.015-0.06 | Ti:0.02-0.20 | Alt≥0.015 |
ST52 E355 16Mn | ≤0.20 | ≤0.55 | 1.00—1.60 | 0.045 | 0.045 | V:0.02-0.15 | Nb:0.015-0.06 | Ti:0.02-0.20 | 16Mn |
25Mn | 0.22—0.30 | 0.17—0.37 | 0.70—1.00 | 0.035 | 0.035 | ≤0.25 | ≤0.25 | ||
27SiMn | 0.24—0.32 | 1.10—1.40 | 1.10—1.40 | 0.030 | 0.030 | ||||
42SiMn | 0.39—0.45 | 1.10—1.40 | 1.10—1.40 | 0.030 | 0.030 | ||||
42CrMo | 0.38—0.45 | 0.17—0.37 | 0.50—0.80 | 0.025 | 0.025 | 0.90—1.20 | 0.15—0.25 |
3. Tube Accuracy :
Working method | Cylinder ID (mm) | Length (m) | Straightness (mm/m) | Tolerance on ID | Tolerance on WT | Roughness (μm) |
Cold drawn | 40-320 | ≤12M | 0.2-0.5 | / | ±5% | 0.8-1.6 |
Cold rolling | 30-100 | ≥12M | 0.2-0.5 | / | ±5% | 0.8-1.2 |
cold drawn-honed | 40-500 | 8M | 0.2-0.3 | H8-H9 | ±5% | 0.2-0.4 |
Cold drawn-skived | 40-400 | 9M | 0.2-0.3 | H8-H9 | ±5% | ≤0.2 |
Hole boring-honed | 320-400 | 8M | 0.2-0.3 | H7-H9 | ±8% | ≤0.4 |
Hole boring-skived | 320-400 | 9M | 0.2-0.3 | H8-H9 | ±8% | ≤0.2 |
