We strive to create 42CrMo seamless cold drawn tube, Cold Drawn Tube, 4140 uniform thickness seamless pipe with reliable performance and customer satisfaction to serve users at home and abroad. We continue to innovate and challenge ourselves to be a growing, profitable, globally operating and diversified company. The company's product development starts from advanced technology at home and abroad, adhering to advanced R&D management concepts. With a wide range, top quality, reasonable rates and stylish designs, our products are extensively used with this industries and other industries. We're going to continually strive to improve our provider and give the very best high quality products and solutions with aggressive charges.
Hard Chrome Plated Pipe Bar Introduction
Chrome plated Honed Tubes are presicion tubes with smooth inside and with chrome plated , they also could be skived and burnished pipe. Tubes or pipes inside tolerance could be H10, H9 or H8. Outside tolerance, wall thickness tolerance are produced according to seamless cold drawn tubes for precision application standard GB/T3639-2009 , EN10305 or DIN2391 standard. Material SAE1020, 20#, ST45, CK45, ST52, E355 tubes and so on for you to choose. IF you are looking for chrome plated tubes for hydraulic cylinder pipes or pneumatic cylinder tubes, please contact us without any hesitation.
Hard Chrome Plated Pipe Bar technical parameters and Details
Application: hydraulic cylinder, pneumatic cylinder, oil cylinder, telescopic cylinder.
Chrome thickness: usually 15 to 20 microns.
Original: Jiangsu, China
Certification: ISO9001.
Material: SAE1020, 20#, ST45, CK45, ST52, E355
Payment term: TT, LC
Delivery date: usually 20 to 40 days.
Packing: packed in bundle, oiled inside, with caps on both ends.
Market: Middle East/ Africa/Asia/South America/Europe/North America
MOQ: Depends on exact size and material.
CK45 quenched and tempered hard chrome plated steel bar
For bar / rods:
1. CHEMICAL COMPOSITION
Material | C% | Mn% | Si% | S% | P% | V% | Cr% |
CK45 | 0.42-0.50 | 0.50-0.80 | ≤0.04 | ≤0.035 | 0.035 | ≤ 0.25 | |
ST52 | ≤0.22 | ≤1.6 | ≤0.55 | ≤0.04 | ≤0.04 | ||
20MnV6 | 0.16-0.22 | 1.30-1.70 | 0.10-0.50 | ≤0.035 | ≤0.035 | 0.10-0.20 | ≤0.30 |
42CrMo4 | 0.38-0.45 | 0.60-0.90 | 0.15-0.40 | ≤0.035 | ≤0.035 | 0.07-0.12 | 0.90-1.20 |
40Cr | 0.37-0.45 | 0.50-0.80 | 0.17-0.37 | ≤0.035 | ≤0.035 | 0.80-1.10 |
2. MECHANCIAL PROPERTIES
Material | T.S N/MM2 | Y.S N/MM2 | E%(MIN) | CHARPY | CONDITION |
CK45 | 610 | 355 | 15 | >41J | NORMALIZE |
CK45 | 800 | 630 | 20 | >41J | Q + T |
ST52 | 500 | 355 | 22 | NORMALIZE | |
20MnV6 | 750 | 590 | 12 | >40J | NORMALIZE |
42CrMo4 | 980 | 850 | 14 | >47J | Q + T |
40Cr | 1000 | 800 | 10 | Q + T |
3. SUPPLY CONDITION
Ground and chrome plated , induction, quenched and tempered
4. CHROME THICKNESS
20 to 30 micron
5. SURFACE ROUGHNESS
Ra≤0.2 micron and Rt≤2 micro
6. TOLERANCES ON DIA
ISO f7 on the diameter
7.OVALITY
Half of the tolerance ISO f7
8. STRAIGHTNESS
≤0.2MM/M
9. SURFACE HARDNESS
850-1150HV (vickers 100g)
10.COHESION
No cracks,breaking or detaching after thermic shock(warming up at 300 celsius degrees and cooling in water)
11 .POROSITY
Test according to ISO 1456/1458 and result yaluation according to ISO 4540 rating 8-10
12. CORROSION RESISTANCE
Test in natural salt spray according to ASTM B 117-72hours
Results evaluation according to ISO 4540 RATING 7-10
13. PACKING
Anti rust oil to be applied on material and each rod to be packed in paper sleeve
We ensure the high quality and excellent performance of the Chrome Steel Tube Round 12mm Diameter, and resolutely prevent unqualified products from leaving the factory. Our products have gained us widespread acceptance and the satisfaction of our worldwide valued clients. All along, we have been adhering to the business tenet of reputation and quality first, pursuit of perfection, and sustainable operation.
